Model

    Digi XBee-PRO 900HP

    Digi Programmable XBee-PRO 900HP

Hardware

Processor

    ADF7023 transceiver, Cortex-M3 EFM32G230 @ 28 MHz

     Programmable includes: Freescale MC9S08QE32

Frequency Band

    902 to 928 MHz, software selectable channel mask for interference immunity

Antenna Options

    Wire, U.FL and RPSMA

Performance

RF Data Rate

    10 Kbps or 200 Kbps

Indoor/Urban Range

    10 Kbps: up to 2000 ft (610 m); 200 Kbps: up to 1000 ft (305 m)

Outdoor/Line-Of-Sight Range*

    10 Kbps: up to 9 miles (14 km);

    200 Kbps: up to 4 miles (6.5 km)( w/2.1 dB dipole antennas)

Transmit Power

    Up to 24 dBm (250 mW) software selectable

Receiver Sensitivity

    -101 dBm @ 200 Kbps, -110 dBm @ 10 Kbps

Features

Data Interface

UART (3V), SPI

GPIO

Up to 15 Digital I/O, 4 10-bit ADC inputs, 2 PWM outputs

Networking Topologies

DigiMesh, Repeater, Point-to-Point, Point-to-Multipoint, Peer-to-Peer

Spread Spectrum

    FHSS (Software Selectable Channels)

Programmability

Memory

N/A

    32 KB Flash / 2 KB RAM

CPU/Clock Speed

N/A

    HCS08 / Up to 50.33 MHz

Power

Supply Voltage

2.1 to 3.6 VDC

    2.4 to 3.6 VDC

Transmit Current

215 mA

    229 mA

Receive Current

29 mA

    44 mA

Sleep Current

2.5 uA

    3 uA

Regulatory Approvals

FCC (USA)

    MCQ-XB900HP

IC (Canada)

    1846A-XB900HP

C-Tick (Australia)

    Yes

Anatel (Brazil)

    Yes

IDA (Singapore)

    Yes
