ELS61 series
Optimized for M2M IoT Solutions
Telit-Cinterion ELS61 wireless module delivers highly efficient Cat 1 LTE connectivity for M2M IoT solutions offering seamless fall back to 2G and 3G networks as well as full VoLTE support on AT&T.
The ELS61-US wireless module features:
|
Model |
ELS61 series |
|
Regional |
NORAM |
|
Frequency Bands |
LTE: 2,4,5,12 3G: 2,4,5 |
|
Certifications |
FCC, PTCRB, IC, UL |
|
Dimensions / Mounting |
27.6 x 25.4 x 2.2mm, LGA |
|
Max. Data Rate DL / UL |
10.3/5.2 Mbps |
|
Embedded Processing |
Java |
|
USB |
USB 2.0 |
|
Serial Interface |
UART, I2C, SPI Digital |
|
Other Interfaces |
GPIO |
This best-in-class solution enables M2M optimized speeds of 10Mbit/s download and 5Mbit/s uplink.
It's ideal for the vast number of M2M and industrial IoT applications that are not dependent on speed, but that require the longevity of LTE networks, while still providing 3G and 2G connectivity to ensure total population and geographic coverage as LTE rolls out.
Applications well suited to the ELS61 solution include metering, tracking and tracing, remote surveillance, connected signs, fleet management, and mHealth solutions.
