AW08-W300

Cellular

Module Support

(1) Digi CORE® modem compliant socket

WI-FI (ON W300 Models only)

Connectivity

2 x 2 MIMO 2.4/5 GHz: 802.11 b/g/n 2.4 GHz or 802.11 n/a/ac 5 GHz

Antennas

RPSMA 2 x 2 MIMO, 2.4 and 5 GHz, 3 dBi gain

Security

Open, enhanced open, WPA, WPA2, WPA3; personal, enterprise

Modes

Wi-Fi client, Wi-Fi access point

Software and management

Remote management

Digi Remote Manager® (cloud based)

Local Management

WebUI (HTTP/HTTPS); CLI (Console, SSH)

Operating Systems

Windows® 7, Windows 8.1, Windows 10; Windows Server® 2012 R2,
Windows Server 2016, Windows Server 2019 and Linux

Protocols

Supports multi-host connectivity for each USB port or group independently

Memory

2 GB RAM, 4 GB flash (eMMC)

Network

Ethernet

(1) RJ-45; 10 M/100 M/1 G/10 G

SFP+

(1) SFP+ socket

Connectors

Console

(1) DB09M; RS-232 DTE

USB

(8) USB 3.1 Gen 1 Type A

USB Port Power

1 A per port (simultaneous)

Physical

Dimensions (L x W x H)

260mm x 160 mm x 44.45 mm (10 in x 6 in x 1.75 in)

Weight

1.58 kg (3.48 lb)

Status Leds

Ethernet, SFP+, 8x USB, power, fan, user,
2x WWAN (if CORE module is inserted),
Wi-Fi (on Wi-Fi models)

Power Requirements

Power Input

12 VDC, 12 A max

Power Consumption

98.5 watts max

Environmental

Operating Temperature

0 °C to 55 °C (32 °F to 131 °F); 0 °C to 40 °C (32 °F to 104 °F) on Wi-Fi models

Relative Humidity

5% to 95% (non-condensing)

Approvals

Safety

UL 62368/60950, EN 62368, IEC 62368, CSA 22.2 62368 -1

Emissions / Immunity

CE, FCC Part 15 Class B, AS/NZS CISPR 22, EN 55024, EN 55032

Warranty

Product Warranty

5 year
